Brand: Merits Health

$2,267.00 $3,346.00
Services and Guarantees
Select to learn more
Free Quick Shipping Free Quick Shipping
Customer Support Customer Support
Price Match Guaranteed Price Match Guaranteed
White Glove Delivery Available White Glove Delivery Available
In Home Services And Repairs Available In Home Services And Repairs Available
Color: Candy Apple Red
Estimated Delivery Time: 3-6 Business Days.
  • 5-Year Limited Warranty

    5-Year Limited Warranty

    This product comes with a limited warranty. Certain parts are covered for up to five years, two years, 18 months, 13 months, and 6 months. There are certain parts that are excluded from the warranty and the warranty can become invalid for certain reasons.

    For the detailed warranty coverage, please: click here.

  • 30-Day Returns. Fees Apply.

    30-Day Returns. Fees Apply.

    This item can be returned this item can be returned within 30 days after receipt and has a 20% restocking fee.

    Other restrictions apply please click here to read more

Top Highlights

Key Features

  • FWD with a 17" turn radius
  • Optional 16"- 20" seat width
  • Semi-reclining ergonomic seat reclines up to 135°
  • Removable shroud for easy maintenance access
  • Large flip-up aluminum footplate, height adjusted.
  • Optional elevating leg-rest kit.
  • 9" knobby drive tires
  • Dynamic LiNX controller for convenient Bluetooth programming and diagnostics

Key Specifications

  • Weight Capacity: 300 lbs.
  • Total Weight: 154 lbs.
  • Heaviest Piece: 62.7 lbs.
  • Turning radius is 17"
  • Ground Clearance: 2.4"
  • Max Speed: 4 mph
  • Driving Range: up to 18 miles

Specifications & Documents
View Product Manual
Product #P322
Weight Capacity300 lbs
DrivetrainFWD
Seat TypeCaptain or Pan
Maximum Speed4 mph
Per-Charge RangeUp to 18 miles
Battery Size2 × 33Ah U1 AGM
Ground Clearance2.4"
Turning Radius17"
Overall Length33"
Overall Width24"
Overall Height37"
Seat-to-Floor Height16.5"–22"
Seat Width16"–20"
Seat Depth16"–20"
Backrest Height18"–20"
Weight of Heaviest Piece62.7 lbs
Total Weight154 lbs
MotorDC 24V, 130W
ControllerDynamic LiNX 40A
Charger4A off-board
Gradient / Maximum Incline6°
Front Wheels3" anti-tippers
Drive Wheels9" diameter foam-filled knobby tires
Rear Wheels6" diameter foam-filled tires
HCPCS CodeK0815 / K0816 / K0820 / K0821 / K0822 / K0823
Color OptionsCandy Apple Red

Warranty & Returns

Returns

  • The item must be unused and in original, brand-new condition
  • All original packaging, materials, manuals, accessories, tools, and protective wrapping must be included
  • The scooter must be returned in its original box with all internal packing materials to prevent damage in transit
  • Returns must be requested within 30 days of the delivery date
  • A 20% restocking fee applies to all approved returns
  • Customers are responsible for return shipping costs unless the return is due to a verified manufacturer defect
  • A return authorization (RMA) must be obtained before shipping the item back
  • The product must not show signs of use, wear, scratches, debris, odors, or tire marks
  • Products that arrive to the warehouse damaged due to improper packaging may be denied or subject to additional fees
  • Battery-powered items must be returned with batteries properly installed and secured as originally packaged
  • Refunds are issued once the item is inspected and approved by the manufacturer

Merits Limited 5-Year Warranty

Merits Health Products, Inc. will repair or replace the following items that have a manufacturing defect. Credit will be given following inspection by an authorized representative of Merits Health Products, Inc. into the material or workmanship.

Warranty Service

Merits Health Products, Inc. retains the right to replace the warranted part(s) with either refurbished or new part(s) at their discretion. Any costs related to labor, service calls, transportation, freight, or other charges associated with the installation of warranted part(s) are the responsibility of the customer. This warranty gives you specific rights and you may also have other rights which may vary from state to state.

5-Year Warranty from the original date of consumer purchase

  • Base Frame
  • Seatbelt

18-Month Warranty from the original date of consumer purchase

  • Joystick / Power Module / Controller
  • Motor / Gearbox / Brake Assembly
  • Circuit Boards
  • Angle Sensor
  • Electrical Harness
  • Charger
  • Transaxle
  • Cushions

13-Month Warranty from the original date of consumer purchase

  • Seat Post / Mount
  • Power Seat Actuator
  • Caster Beam
  • Joystick Mounting Bracket
  • Metal Sitting Frame
  • Anti-Tipper Assembly
  • 31Ah or above batteries
  • Powered Footplate
  • Armrest Bracket (metal part only)
  • Caster Forks

6-Month Warranty from the original date of consumer purchase

  • Bearings / Bushings
  • Front Riggings
  • Non-Powered Footplate
  • Swivel Seat Mechanism
  • Batteries less than 31Ah supplied by Merits

2-Year Warranty from the original date of consumer purchase

  • Non-Wear Components
  • Circuit Boards
  • Fasteners
  • Electrical (Harness & Switches)

Warranty Exclusions: The following items are excluded from warranty

  • Tires & tubes
  • Fuses & bulbs
  • Battery cases
  • Plastic / rubber parts
  • Motor brushes
  • Brake pads
  • Upholstery including seat/arm pads/padding
  • Painted surfaces including shrouds/fender

Warranty becomes invalid on any parts damaged from

  • Acts of nature, loss, or theft
  • Commercial use
  • Neglect, improper operation, or maintenance/repair
  • Units altered or serviced by an agency not authorized by Merits Health Products, Inc.
  • Serial-numbered products if the serial number has been removed or defaced

Part(s) purchased outside of warranty have 90 days to report manufactured defect

Description

Merits has been first started in Taiwan in 1986 and expanded into the U.S.A. in 1989. They specialize in selling mobility scooters, electric wheelchairs, and stairlifts. They've been a respected name in the industry for decades known for their fast shipping, reliable products, and great support.

Their mission is to enhance independence and accessibility for all—empowering people to live life to the fullest with reliable, purpose-built products designed for comfort, confidence, and long-lasting performance.

You can learn more about what they sell by clicking here.

Front-wheel drive built for exceptionally tight maneuvering

The Merits Vision CF combines front-wheel drive with a 17-inch turning radius, giving it particularly compact maneuverability for a full-size power wheelchair. The drive wheels lead the chair through turns, making the Vision CF well suited to navigating homes, hallways, shops, and other spaces where turning room matters.

Adjustable seating with up to 135° of recline

The Vision CF can be configured with 16" to 20" seat widths and seat depths, providing several options for matching the chair to your preferred fit.

Its ergonomic seating semi-reclines up to 135°, allowing you to change your seating position throughout the day. An optional elevating leg-rest kit is also available for additional positioning flexibility.

A large footplate and simplified frame add everyday practicality

A large flip-up aluminum footplate provides a substantial foot platform and moves out of the way when needed. The chair's simplified frame also uses a removable shroud, providing easier access to internal components for maintenance.

Knobby drive tires pair with a compact FWD platform

The Vision CF uses 9-inch foam-filled knobby drive tires, eliminating the need to monitor tire pressure while providing a tread pattern designed for additional traction.

Its 2.4 inches of ground clearance and front-wheel-drive configuration complement a chair primarily designed around maneuverability and everyday mobility rather than the larger footprint of heavier power-chair platforms.

Dynamic LiNX brings programming and diagnostics to the controller

The Dynamic LiNX 40A controller supports Bluetooth programming and diagnostics, giving providers and technicians convenient access when the chair requires configuration or servicing.

With a 4 mph maximum speed, up to 18 miles of range, and a 300 lb weight capacity, the Vision CF combines its compact handling with practical everyday performance.

A full-size chair centered on maneuverability and adjustability

At 154 lbs total, with a 62.7 lb heaviest piece, the Vision CF is lighter than some full-size power wheelchairs but is not designed around frequent manual lifting.

If you plan to transport it regularly, a compatible vehicle lift can make loading and traveling with the chair more practical without requiring you to manually handle its substantial weight.

Its combination of true front-wheel drive, a 17-inch turning radius, customizable seating, semi-recline, and Dynamic LiNX controls makes maneuverability and configuration the central strengths of the Vision CF.
